مكان المنشأ:
الصين
إصدار الشهادات:
ce
رقم الموديل:
AK6-APL110-C007R
| Item | Specification |
|---|---|
| Rated Voltage | 180V-240V AC, 50Hz |
| Power Consumption | ≤5VA |
| Operating Environment | Ambient temperature: 0-50°C Relative humidity: 35%-85% RH (non-condensing) |
| Storage Temperature | -25°C-65°C (no condensation or frost) |
| Resolution | 1°C, 0.1°C (optional) |
| Wiring Method | Terminal connection |
| Measurement Accuracy | ±0.5%FS |
| Data Retention | Non-volatile memory |
| Installation Environment | Indoor installation, free from corrosive gases |
| Relay Output | Relay control output: AC220V/DC30V, 3A |
| Analog Output | (Optional) DC12V: 0-5V/1-5V; DC0-5V/1-5V; Output current: ≤30mA; Load resistance ≥1kΩ |
Please refer to the following code description to confirm whether the delivered product model matches the selected one.
Unit: mm
| Model | Panel Size (mm) | Overall Dimensions (L × W × H, mm) | Mounting Hole Size (mm) |
|---|---|---|---|
| AK6-A | 48 × 48 | 76 × 45 × 45 | 46 × 46 |
| AK6-B | 48 × 96 | 72 × 44 × 90 | 45 × 91 |
| AK6-D | 72 × 72 | 72 × 66 × 66 | 67 × 67 |
