اسم العلامة التجارية:
Yokogawa
رقم الموديل:
SC29
| Model | Specifications |
|---|---|
| SC29(C)-PT29 |
Combined reference/reference electrode (Non-flow type)
Measuring range: -1500...1500mV
Temperature range: -10 to 100°C
Pressure range: 1.5 kPa...500 kPa
Membrane: Solid Platinum cup
Diaphragm: Porous PTFE (Impedance <5 kΩ)
Reference system: Ag/AgCl Saturated KCl
|
| SC29(C)-PT55 |
Combined reference/reference electrode (Flow type)
Temperature range: -10 to 100°C
Pressure range: 1.5 kPa...500 kPa
Membrane: Solid Platinum cup
Diaphragm: Ceramic (Impedance <5 kΩ)
Reference system: Ag/AgCl 3.3m KCl
|
| SC29-PtG29 |
Combined reference/glass electrode
Temperature range: 0 to 100°C
Pressure range: 1.5 kPa...1000 kPa
Membrane: Solid Platinum
Glass: General purpose pH glass
|
| Model | Package Size | Weight |
|---|---|---|
| SC21(C), SC29(C) | 120*45*45 mm (10.6*2*1 in) | 0.08 kg (0.17 lbs) |
| SC21(C-AGESS, SC29C-PT55 | 300*95*73 mm (11.8*3.7*2.9 in) | 0.22 kg (0.48 lbs) |
