Water Treatment Fluid Level Meter Integrated With English Led Display

Water Treatment Fluid Level Meter Integrated With English Led Display

ultrasonic level transmitter,ultrasonic liquid level sensor

ultrasonic liquid level sensor

مكان المنشأ:

الصين

اسم العلامة التجارية:

KACISE

إصدار الشهادات:

CE

Model Number:

KUM-A

نتحدث الآن
نتحدث الآن
تفاصيل المنتج
Product type:
integrated
Power Supply:
24 VDC Optional: 220V AC+15% 50Hz
Display:
English Led Display
Cable Probe:
No
Digital Output:
RS485
Resolution:
3mm or 0.1%
Apply:
Water Treatment
Product Name:
Integrated Type KUM-A Ultrasonic Level Meter Used in Water Treatment of High Quality
إبراز:

ultrasonic level transmitter,ultrasonic liquid level sensor

,

ultrasonic liquid level sensor

شروط الدفع والشحن
الحد الأدنى لكمية
قطعة واحدة
الأسعار
USD157 to USD610 per pc
Packaging Details
each unit has individual box and all boxes are packed in standard packages or customers requests available
Delivery Time
5-8 work days
Payment Terms
T/T, Western Union, MoneyGram
القدرة على العرض
1000 قطعة / قطع أسبوع قابل للتفاوض
وصف المنتج

Integrated Type KUM-A Ultrasonic Level Meter Used in Water Treatment of High Quality



KUM-A ultrasonic level meter is a non-contact and cost-effective level meter with high reliability, high accuracy and easy installation. It does not have to contact the medium and can meet the measuring requirements of most applications.



Technical Features:

  • Non-contact, can be used in various applications;
  • Various types of probes are available to meet the requirements of various applications.
  • High accuracy: 0.5%, 1%
  • English LED Display





Technical Specifications:



Specs Value
Pressure Voltage 5m, 10m, 15m, 20m, 30m, 40m, 50m, 60m
Accuracy 0.5%, 1.0%
Display LCD
Ambient Temperature Display instrument-20~+60℃
transducer-20~+80℃
Medium liquid and solid
Analog Output 4-20mA
Digital Output RS485, RS232 (both are optional)
Power Supply 24Vdc
Protection Grade Display instrument IP65,transducer IP68
Probe Type PVDF, aluminum alloy, ABS, stainless steel 316L, teflon, titanium alloy





Structure:

Water Treatment Fluid Level Meter Integrated With English Led Display 0

Model Selection:



KUM-A
  Measurement Range
A 5m
B 10m
C 15m
D 20m
E 30m
F 40m
G 50m
H 60m
  Output Signal
A 4-20mA
  Accuracy
0.5 0.5%
1.0 1%
  Power Supply
A 24Vdc
B 11~30Vdc
  Probe Type
A PVDF
B Aluminum alloy
C ABS
D Stainless steel 316L
E Teflon
F Titanium alloy



 Applications and Installations:

  • Distance measurement
  • Depth measurement



Water Treatment Fluid Level Meter Integrated With English Led Display 1

Water Treatment Fluid Level Meter Integrated With English Led Display 2

Water Treatment Fluid Level Meter Integrated With English Led Display 3

Structure:
