Place of Origin:
CHINA
اسم العلامة التجارية:
kacise
إصدار الشهادات:
CE
Model Number:
KRC601
Used in drinking water treatment plant, canning plant, drinking water distribution network, swimming pool, cooling circulating water, water treatment project, etc. .
| Model number | KRC601 |
|
Measuring principle |
Constant voltage method |
| Range Range | 0ー2.000 mg/L (HClO) |
| Resolution | 0.001 MGL |
| Precision | ± 5% or ± 0.05 mg/l, ± 0.5 °C |
|
Calibration function |
Two-point calibration |
| Working pressure | < 0.1 mpa |
|
The pH range of the medium |
4 ~ 9 ph |
|
Temperature compensation |
Automatic temperature compensation (PT1000) |
| Signal output | RS-485(Modbus/RTU) |
| Shell material | Pom, polytetrafluoroethylene |
|
Operating temperature |
5 ~ 50 °C |
| Installation mode | Circulation Pool installation |
| Dimensions | 30 × 233 mm |
| Velocity of flow | 30 ~ 60 L/h |
| Response time | < 30s |
| Power consumption | 0.2W@12V |
| Power supply | 12 ~ 24 VDC |
| Protection level | IP68 |
3.Dimensional Drawing
Note: Sensor Connector is M16-5 core waterproof connector
